"D imensions mm ft-in Length 7820 25' 8" Wi dth 2550 8' 4" H eight 2670 8' 9" C apacity Litres Gallons 35,000 7,720 S hell Material 316L Stainless Steel B arrel/ 4.2/5.0 mm (.165/.197") H ead Thickness Pr essures Wo r king = 3 Bar (43.5 psi) T est = 6 Bar (87.0 psi) V acuum = 0.4 Bar (5.9 psi) D esign Temp 130°C (266°F) D esign Code ASME VIII Division 1 E xternal Finish Z inc rich primer and chlorinated rubber top coat. I nternal Finish Cold rolled ASTM 2B, interior acid cleaned and certified for the carriage of foodstuff. W eights kgs lbs Ta re 4,200 9,259 M ax Payload 29,800 65,694 Fi ttings M anlid Fort Vale 500 mm, fully hinged with 6 fixings. Air Line 1 1 ? 2 " Fort Vale stainless steel butterfly valve with a 2" BSP termination. Bottom Outlet 3" 45° stainless steel steam heated foot valve, butterfly v alve with a 3"BSP termination. R emote closure system fitted. To p Outlet 3" nominal bore closed by a 3" blind flange. S afety Relief 1 - 3" flanged pressure only V alve valve set at 4.4 Bar. Thermometer Surface type gauge reading 0 °C to +200 °C (32 °F/+392 °F). S team and Glycol 8 off vee sections producing an H eating System effective heating area of 9 sq.meters (97 sq.ft) at 3 Bar. (43.5 psi) working pressure. S ystem is fitted with glycol pipe work. I nsulation 80 mm aluminium foil backed/rockwool insulation with outer cladding of white GRP. A pprovals ADR, RID, IMDG, TIR, UIC, CSC. S huttle Codification. O ther Capacities Fr om/To Litres Gallons 26,000 5,720 35,000 7,720 O ptions E lectrical Heating. Ba f fles or compartments. Gl y col System. G eneral Specifications Sw ap Body Tank T11/35 01/03 9, Place Hoche - F - 78000 V ersailles, F rance. tel: 33-1-39 51 16 12 fax: 33-1-30 21 91 96 email: sales.europe@EXSIFWW.COM 1225 North Loop West S uite 300, Houston TX 77008, USA tel: 1-713-869-9922 fax: 1-713-869-6526 email: sales.americas@EXSIFWW.COM V isit our web site WWW . EXSIFWW . COM 16 Raffles Quay #42-01A Hong Leong Building S ingapore 048581 tel: 65-6224-2633 fax: 65-6224-2634 email: sales.asia@EXSIFWW.COM Of fices and Agents Worldwide: Australia, Brazil, China, France, Germany, Indonesia, Israel, Italy, Japan, Korea, Netherlands, M alaysia, P hilippines, Poland, Russia, Saudi Arabia, Singapore, South Africa, Taiwan, United Arab Emirates, UK, USA H eadquarters: 100 Manhattanville Rd, Purchase, NY 10577, USA tel: 1-914-697-2600, fax: 1-914-697-2697, e-mail EXSIF . CO @ EXSIFWW . COM N ote: The above information is an average representation of technical data. Please consult your EXSIF Worldwide representative for more specific data."
